The single-cylinder hydraulic cone crusher has the characteristics of advanced structure design, strong crushing capacity, good reliability and low production and operation cost. Through a single hydraulic cylinder, the cone can be lifted and lowered, and various functions such as discharge port adjustment, cavity cleaning, iron passing, and overload protection are realized.
24HOURS：+86 15237197009
The single-cylinder hydraulic cone crusher realizes various functions such as adjustment of the discharge port, cavity cleaning, iron passing and overload protection through the lifting and lowering of the cone by a single hydraulic cylinder; it is equipped with an electronic intelligent discharge port control system to achieve more production process control and Job optimization function.
Advantages1. The high-efficiency rotating speed feeding hopper makes the lining plate wear evenly and evenly.
2. The parts are made of high-quality steel, with reliable performance and safer operation.
3. Automatic overload protection to avoid shutdown due to iron lock entry.
4. Simple structure, easy to replace or maintain the wearing parts.
The products and production lines designed by our experienced engineers are widely used in various ore flotation, magnetic separation and other beneficiation industries.
Ore Crushing
High yield/Efficiency/Low cost
Ore Screening
Quality First / Precise Grain Size
Ore Grinding
Granularity meets requirements
Magnetic Separation
Simple Structure/Easy Operation
Flotation Process
Low Investment/High Return
Technical Parameters| Model | Cavity | Max Feed Size(mm) | min-max(mm) | Capacity(tph) | Power KW(HP) |
| HST100 | S1(Extra Coarse) | 240 | 22-38 | 85-170 | 90(125) |
| S2(Medium Coarse) | 200 | 19-32 | 70-130 | 90(125) | |
| HST160 | S1(Extra Coarse) | 360 | 25-54 | 120-345 | 132(175) |
| S2(Medium Coarse) | 300 | 22-48 | 105-305 | 132(175) | |
| S3(Coarse) | 235 | 19-48 | 90-275 | 132(175) | |
| HST250 | S1(Extra Coarse) | 450 | 35-54 | 255-605 | 220(300) |
| S2(Medium Coarse) | 400 | 29-51 | 215-515 | 220(300) | |
| S3(Coarse) | 300 | 25-51 | 190-490 | 220(300) | |
| HST315 | S1(Extra Coarse) | 560 | 41-76 | 335-1050 | 315(400) |
| S2(Medium Coarse) | 500 | 38-70 | 305-895 | 315(400) |
Related Cases
Product Introduction
Advantages
Technical Parameters
Throughput：150 t/h
Material：Gold ore
